ALUMINIUM Z CLAMP

A Solar Z Clamp, also known as a mid clamp or inter clamp, is a key component used in solar panel mounting systems, particularly for securing photovoltaic (PV) modules to mounting rails. It is typically installed between two solar panels and serves the purpose of holding them firmly in place while ensuring structural stability and safety. The "Z in the name refers to the clamps shape, which resembles the letter "Z when viewed from the side. Made usually from high-strength anodized aluminum or stainless steel, the Z clamp is corrosion-resistant and suitable for outdoor use, withstanding various environmental conditions such as rain, wind, and UV exposure. It typically includes a bolt, nut, and the Z-shaped body, which grips the edge of the solar panel frame and locks into the mounting rail underneath. The clamp must match the thickness of the solar panel framecommon sizes are 30mm, 35mm, 40mm, and so on. Installation of a Z clamp requires alignment with pre-drilled rail slots, and the clamp is tightened to provide a firm grip without damaging the panel. Proper torque and spacing are essential for safety and compliance with engineering standards. The Z clamp plays a crucial role in ensuring the mechanical integrity of a solar PV system by allowing thermal expansion, withstanding wind uplift, and maintaining the correct panel spacing for optimal performance and heat dissipation.
